Summoners (Tabs)

About

Summoner is the name given for some type of tabs, for example the My Blueprint, Graph Editor, Construction Script Editor. An easy example of them being used is the Blueprint Editor.

They are tabs BOUND to an asset. They have special features such as:

• You can only have one tab for each of these “tab category” (See the checkmark on the left)
• You can move them around, but they will be closed if you close the bound asset editor.
• Their “existence” and docking position will be restored if you reopen the asset. Saving up time

To see how the Blueprint Editor ones are made see BlueprintEditorTabFactories.h/.cpp and BlueprintEditorModes.h/.cpp files.

Add your custom summoners

Blueprint Editor Setup

Steps

Do it in an editor module. Here we are adding a summoner tab for the Blueprint Editor, I didn’t test for other asset types.

First, make your summoner struct type

// the summoner struct type
struct PREFABSYSTEMEDITOR_API FPSPrefabSystemBlueprintSummoner : FWorkflowTabFactory
{

public:
	FPSPrefabSystemBlueprintSummoner(TSharedPtr<FBlueprintEditor> InBlueprintEditorPtr);

	virtual TSharedRef<SWidget> CreateTabBody(const FWorkflowTabSpawnInfo& Info) const override;

	virtual FText GetTabToolTipText(const FWorkflowTabSpawnInfo& Info) const override;
};

// summoner body in .cpp
FPSPrefabSystemBlueprintSummoner::FPSPrefabSystemBlueprintSummoner(TSharedPtr<FBlueprintEditor> InBlueprintEditorPtr)
    : FWorkflowTabFactory("TempUniqueIdForPRefabSumoner", InBlueprintEditorPtr)
{
	TabLabel = INVTEXT("Test tab label");
	TabIcon = PS::Editor::Helpers::GetPrefabSystemIcon();

    bIsSingleton = true;
    InsideTabPadding = 10;

    ViewMenuDescription = INVTEXT("ViewMenuDescription");
    ViewMenuTooltip = INVTEXT("ViewMenuTooltip");
}

TSharedRef<SWidget> FPSPrefabSystemBlueprintSummoner::CreateTabBody(const FWorkflowTabSpawnInfo& Info) const
{
    return SNew(STextBlock).Text(INVTEXT("Prefab Summoner test"));
}

FText FPSPrefabSystemBlueprintSummoner::GetTabToolTipText(const FWorkflowTabSpawnInfo& Info) const
{
    return INVTEXT("Test tooltip");
}


Next, register it

// Call this after GEditor is valid, a simple way of doing that is using FCoreDelegates::OnPostEngineInit
FBlueprintEditorModule& BlueprintEditorModule = FModuleManager::LoadModuleChecked<FBlueprintEditorModule>("Kismet");
BlueprintEditorModule.OnRegisterTabsForEditor().AddLambda([] FWorkflowAllowedTabSet& TabSet, FName ModeName, TSharedPtr<FBlueprintEditor> BlueprintEditor)
{
	TabSet.RegisterFactory(MakeShared<FPSPrefabSystemBlueprintSummoner>(BlueprintEditor));
});

And now, its done!

How does the injection work

It seems that FBlueprintEditorUnifiedMode::FBlueprintEditorUnifiedMode constructor is used by default when you open a blueprint.

It registers the summoners in BlueprintEditorTabFactories. The same tab set is used in FBlueprintEditorUnifiedMode::RegisterTabFactories. We are using the OnRegisterTabsForEditor lambda, which is called BETWEEN the two mentioned function, allowing us to add summoners BEFORE its pushed to the FBlueprintEditor.

If you want to add the summoner tab in another way, you could by having a TSharedptr<FBlueprintEditor>.

FWorkflowAllowedTabSet WorkflowAllowedTabSet;
WorkflowAllowedTabSet.RegisterFactory(MakeShared<FPSPrefabSystemBlueprintSummoner>(BlueprintEditorPtr));
BlueprintEditor->PushTabFactories(WorkflowAllowedTabSet);
